Revolt RVX Official Specifications: The Complete, Verified Spec Sheet (2026)

Spec aggregator sites frequently show conflicting numbers for the same electric motorcycle, we've seen this problem firsthand researching other bikes for this blog. To avoid that here, this article presents theRevolt RVX's specifications exactly as they appear on the manufacturer's official, signed specification documentation, with every claimed figure clearly marked.

Performance

• Segment: Sports

• Top Speed (Boost Mode): 90 Kmph*

• Mode-Specific Top Speeds: Boost 90 Kmph, Sports 80 Kmph, City 65 Kmph*, Eco 50 Kmph*

• Peak Motor Rating: 5.3 kW

• Motor Type: Mid Drive PMSM

• Max Torque (At Motor): 50 Nm

• Max Torque (At Wheel): 230 Nm

• Acceleration (0-40 Kmph): 3.9 Sec*

• Gradability (1 Person): 14 Deg.*

• Gradability (2 Persons): 11.5 Deg.*

• IP Rating (Motor & Controller): IP67

• Drive System: Chain Drive, Front Sprocket 13T, Rear Sprocket 60T, Chain 120L

Battery

• Capacity: 3.24 kWh

• Functionality: Removable

• Chemistry: NMC

• Cooling System: Passive

• IDC Range: 160 Km/Charge*

• IP Rating (Battery Pack): IP67

• Warranty: 8 Years or 80,000 km, whichever comes first

Charging

• Charging Time (0-80%): 3 Hrs 30 Mins

• Charger Type: Offboard

• Charger Rating: 10 A

• Fast Charging Time (0-80%, optional): 80 Mins

• Fast Charging Rating: 27 A

Tyres and Wheels

• Wheel Type: Alloy

• Front Wheel Rim Size: MT 2.15 x 17

• Rear Wheel Rim Size: MT 3.00 x 17

• Front Tyre: 90/80 - 17, Tubeless

• Rear Tyre: 110/80 - 17, Tubeless

• Ground Clearance: 190 mm

Brakes and Suspension

• Braking System: CBS (Combined Braking System)

• Brake Type: Front Disc, Rear Disc

• Front Suspension: Upside Down Fork

• Rear Suspension: Monoshocker

Dimensions

• Kerb Weight: 117 Kgs

• Payload Capacity: 150 Kgs

• Overall Dimensions (L x W x H): 2040 x 710 x 1073 mm

• Wheel Base: 1340 mm

• Seat Height: 815 mm

Electrical and Cluster

• Lighting: LED (headlight, DRL, tail light, indicators)

• Vehicle Start System: Push Button with Remote Key

• Screen Size: 3.5 Inch

• Display Type: PMVA (Colour)

Smart Features

• Mobile App Connectivity: Yes

• GPS: Yes

• Bluetooth Connectivity: Yes

• Geo-Fencing: Yes

• OTA Updates: Yes

• Immobilization (Remote Vehicle On/Off): Yes, Limited

• Vehicle Locator: Yes

• Reverse Mode: Yes

• Hill Hold: Yes

• Walk Assist: Yes

• Boost Mode: Yes

• Call/Message Alerts on Cluster: Yes

• Seat & Handle Lock: Manual Key
